Refitting

- Position the vehicle on a lift.

- Raise the vehicle.

1. Working behind the left rear wheel, loosen the fastening screws (1a) of the supplementary wheel arch (1b).

1. Working behind the left rear wheel, loosen the fastening screws (1a) of the fog light (1b).

2. Move the fog light and release the retainer (2a) from its seat.

3. Detach the electrical connection.

4. Recover the rear fog light.

Removing

- Check that the rear fog lamp is not damaged.

- Connect the electrical connection.

- Position the rear fog lamp and attach the retainer in the seat.

- Tighten the light retaining bolt.

- Position the supplementary wheel arch and tighten the fixing bolts.

- Remove the vehicle from the lift.

- Check that the rear fog lamp is working.
