145 - MiTo   1.4 16v TJet   SPARK PLUGS - R+R   5510D10

Detail     Detail
Removing ( Refitting )

   Op. 1016A10 SOUND-PROOFING COVER - R.R

   Op. 1080D24 ENGINE OIL VAPOUR INTAKE PIPE - R + R

   Op. 5510C14 IGNITION COIL/S - R.R.


Enlarge the image

1. Undo and remove the spark plugs (1b) using a suitable spanner (1a).
Refitting ( Removing )

Using different spark plugs from the recommended ones can cause damage to the engine and alter the exhaust emission levels.

Enlarge the image

1. Fit the spark plugs (1a) in their seats and tighten them to the recommended torque using a suitable spanner (1b).



Component



Fixing



dia



Value (daNm)



Validity


Spark plugs



-



M12



1.6 รท 2.0



1.4 16v TJet

1.4 8V

1.4 16v

1.4 MultiAir

1.4 Turbo MultiAir

0.9 TwinAir

    Op. 5510C14 IGNITION COIL/S - R.R.

    Op. 1080D24 ENGINE OIL VAPOUR INTAKE PIPE - R + R

    Op. 1016A10 SOUND-PROOFING COVER - R.R
